BRGB20T-2MT

Mini-WECO (Midsize), Component 3-Wire (RGB), 2x10, 2 RU

  • Bittree® Mini-WECO (Midsize) Video Patchbay in 2 RU Height with 2x10 RGB Circuit Configuration

    Mini-WECO Video Jack Properties:
    • High-bandwidth performance for SD/SDI, HD/SDI, 3 Gb/s and 3D applications
    • SMPTE 259M, 292M and 424M compliant
    • True 75 ohm impedance with low return loss

    Panel Features:
    • 3/16" (0.187 in. / 4.76 mm) machined aluminum with a durable powder-coat finish
    • Offset chevron design ensures correct patch cable insertion
    • Rear-mounted jack modules
    • Precision machined phenolic insulator electrically and mechanically separates jacks from the front panel
    • 2 x DS870-10 Designation Strips:
    - Stainless-steel slider with white styrene and non-glare Lexan inserts
    • BNC Rear Interface

    Options:
    • Mini-WECO video jacks may be ordered in four different configurations:
    - Dual body, self-normalling with 75 ohm termination (2MWTHD)
    - Dual body, self-normalling, non-terminating (2MWNHD)
    - Dual body, non-normalling (straight-through) with 75 ohm termination (1MWTHD)
    - Dual body, non-normalling (straight-through), non-terminating (1MWNHD)

    Compliance:
    • RoHS Compliance – See our RoHS compliance statement to learn more





  • Product Files:
    Circuit Schematics Coming Soon
    Designation Strip Template Coming Soon
    Technical Drawings:
    BRGB20T-2MT Coming Soon Coming Soon
    BRGB20T-2MN DWG PDF
    BRGB20T-1MT DWG PDF
    BRGB20T-1MN DWG PDF

Category: Legacy

Type: Legacy
