Riedel Artist® Intercom Patchbay, TT (Bantam), 2 RU, E3/RJ45 Rear Interface

B24E3ARTIST/D

Continue Shopping or Checkout



  • Bittree® Programmable Riedel Artist® Intercom Patchbay in 2 RU
    • High-density 2x2x24 circuit configuration
    • Ships preconfigured with your preferred Normalling configuration; grounds are isolated
    • Circuits can be easily reprogrammed via shunts under the top dust cover

    TT (Bantam) Jack Properties:
    • Rated to 30,000 minimum insertion cycles
    • Copper-nickel-silver alloy leaf springs with gold-alloy cross bar switching contacts and nickel-plated sleeve bushings
    • Rugged nickel-plated, cold-rolled steel box-frame construction

    Panel Features:
    • 3/16” (0.187 in. / 4.76 mm) machined aluminum with a durable powder-coat finish
    • Precision machined phenolic insulator electrically and mechanically separates jacks from the front panel
    • 12" (30.48 cm) deep fully enclosed chassis
    • 3 x DS580-10 designation strips (stainless-steel sliders with white styrene and non-glare Lexan inserts)
    • E3/RJ45 rear interface with E3 mating hardware included:
    - 48 x E3M connector housings (3-pin male)
    - 144 x EPIN crimp contacts (gold-plated)

    Options:
    • Normalling – circuits can be programmed to full normal with digital RJ45 pinout, or half normal with analog RJ45 pinout

    Compliance
    • RoHS Compliance – See our RoHS compliance statement to learn more





  • Product Files:
    Technical Document PDF
    Designation Strip Template DOCX
    12 in. Chassis - Technical Drawings:
    B24E3ARTIST/D DWG PDF
    B24E3ARTIST DWG PDF
